AP9614 APC Dry Contact I/O SmartSlot Card

Available at Sevenbridge Technology LLC, APC Dry Contact I/O SmartSlot Card, in Dubai, UAE.

Specifications

Brand APC
Model : AP9614
Product Type Dry Contact I/O SmartSlot Card
Compatible UPS Interface SmartSlot (for compatible APC UPS units)
Function Provides dry contact inputs/Output : s for external device monitoring and control
Output : Relays 6 configurable Output : relays
Input Contacts 4 input contact terminals
Universal I/O Ports 2 Universal I/O ports for optional sensors/accessories
Rated Voltage 24?V dry contact operation
Line Rated Current 0???200?mA
Power Source Powered via UPS SmartSlot (no external PSU required)
Supported Monitoring Web-based configuration and status monitoring
Physical Dimensions (approx.) 3.8?cm (H) ? 12.1?cm (W) ? 12.8?cm (D)
Net Weight ~0.20?kg
Operating Temperature 0???40??C
Operating Altitude 0???10,000?ft
Storage Temperature ?15???65??C
Form Factor 0U SmartSlot plug-in card
Included Accessories USB cable for local configuration, user manual
Mounting Mode Plugs into UPS SmartSlot management slot
Use Cases External alarm panels, environmental sensors, automation interfaces, facility management alerts
